Product Detail
DC-link capacitors (box type)
Type: : LM series
Spec : 1-80μF/500-1200VDC
Description : DC-link,DC filtering
Application : UPS | Frequency inverter | Solar inverter | Plating power supply | Inverter welding machine for DC filter.
Detail

  ELECTRICAL CHARACTERISTICS

容量范围   Capacitance Range

180μF

使用温度   Operating Temperature

-400C~+850C

容量偏差   Capacitance Tolerance

±5%(J);±10% (K)

额定电压   Rated Voltage

5001200V.DC

耐电压     Test Voltage between Terminal

1.5Un 60s

过电压     Operating voltage

1.10Un(30% of on load duration)

1.15Un(30mins/day)

1.2Un(5mins/day)

1.3Un(1min/day)

绝缘电阻   Insulation Resistance

R*C5000S(100VDC, 60S,20℃)

海拔       Max.Altitude

4000m

阻燃性     Flame Resistance

UL 94V-0

预期寿命   Lifetime Expectancy

≥100,000Hours (Un,≤70℃)

失效率     Failure

50FIT


应用于:

UPS | 小功率变频器 | 光伏逆变器 | 电镀电源 | 逆变焊机 等设备的直流滤波及支撑。



Download 点击下载规格书
