Product Detail
LL series DC-link capacitors
Type: : LL series
Spec : 100-2,000μF,800-3000VDC
Description : DC-link/DC-filter/energy storage capacitor
Application : Inverter ,converter,power supply for dc-link
Detail

ELECTRICAL CHARACTERISTICS

容量范围   Capacitance Range

483500μF

使用温度   Operating Temperature

-400C~+850C

容量偏差   Capacitance Tolerance

±5%(J);±10% (K)

额定电压   Rated Voltage

4008000V.DC

耐电压     Test Voltage between Terminal

1.5Un 60s

极壳耐压   Test Voltage between Terminal/Case

√2*Un≤1000,2000VAC(60s)

2*Un>1000,(2*Un+1000)VAC(60s)

绝缘电阻   Insulation Resistance

R*C5000S(100VDC, 60S)

海拔       Max.Altitude

2000m

阻燃性     Flame Resistance

UL 94V-0

电极扭矩   Max Torque of terminals

6Nm

安装扭矩   Max Torque of installation

10Nm

预期寿命   Lifetime Expectancy

≥100,000Hours (Un≤85℃)

失效率     Failure

50FIT


应用于:   风电逆变器/ 太阳能逆变器/ 电焊机/ 变频器/ 开关电源/ 电镀电源/ 不间断电源等设备的直流支撑、储能和滤波。

Application: Wind power,Solar power,Welding machine,Frequency converter,Switch power supply,Plating power supply,UPS. For DC-link,energy storage and filter.
